Description

The SPC560B40x/50x and SPC560C40x/50x is a family of next generation microcontrollers

built on the Power Architecture embedded category.

The SPC560B40x/50x and SPC560C40x/50x family of 32-bit microcontrollers is the latest

achievement in integrated automotive application controllers. It belongs to an expanding

family of automotive-focused products designed to address the next wave of body

electronics applications within the vehicle. The advanced and cost-efficient host processor

core of this automotive controller family complies with the Power Architecture embedded

category and only implements the VLE (variable-length encoding) APU, providing improved

code density. It operates at speeds of up to 64 MHz and offers high performance processing

optimized for low power consumption. It capitalizes on the available development

infrastructure of current Power Architecture devices and is supported with software drivers,

operating systems and configuration code to assist with users implementations.

Features
· High-performance 64 MHz e200z0h CPU
– 32-bit Power Architecture® technology
– Up to 60 DMIPs operation
– Variable length encoding (VLE)
· Memory
– Up to 512 KB Code Flash with ECC
– 64 KB Data Flash with ECC
– Up to 48 KB SRAM with ECC
– 8-entry memory protection unit (MPU)
· Interrupts
– 16 priority levels
– Non-maskable interrupt (NMI)
– Up to 34 external interrupts incl. 18 wakeup
lines
· GPIO: 45(LQFP64), 75(LQFP100),
123(LQFP144)
· Timer units
– 6-channel 32-bit periodic interrupt timers
– 4-channel 32-bit system timer module
– Software watchdog timer
– Real-time clock timer
· 16-bit counter time-triggered I/Os
– Up to 56 channels with PWM/MC/IC/OC
– ADC diagnostic via CTU
· Communications interface
– Up to 6 FlexCAN interfaces (2.0B active)
with 64-message objects each
– Up to 4 LINFlex/UART
– 3 DSPI / I2C
· Single 5 V or 3.3 V supply
· 10-bit analog-to-digital converter (ADC) with up
to 36 channels
– Extendable to 64 channels via external
multiplexing
– Individual conversion registers
– Cross triggering unit (CTU)
· Dedicated diagnostic module for lighting
– Advanced PWM generation
– Time-triggered diagnostic
– PWM-synchronized ADC measurements
· Clock generation
– 4 to 16 MHz fast external crystal oscillator
(FXOSC)
– 32 kHz slow external crystal oscillator
(SXOSC)
– 16 MHz fast internal RC oscillator (FIRC)
– 128 kHz slow internal RC oscillator (SIRC)
– Software-controlled FMPLL
– Clock monitor unit (CMU)
· Exhaustive debugging capability
– Nexus1 on all devices
– Nexus2+ available on emulation package
(LBGA208)
· Low power capabilities
– Ultra-low power standby with RTC, SRAM
and CAN monitoring
– Fast wakeup schemes
· Operating temp. range up to -40 to 125 °C
