Description

STM32F412XE/G devices are based on the high-performance Arm® Cortex® -M4 32-bit

RISC core operating at a frequency of up to 100 MHz. Their Cortex®-M4 core features a

Floating point unit (FPU) single precision which supports all Arm single-precision data

processing instructions and data types. It also implements a full set of DSP instructions and

a memory protection unit (MPU) which enhances application security.

STM32F412XE/G devices belong to the STM32 Dynamic Efficiency™ product line (with

products combining power efficiency, performance and integration) while adding a new

innovative feature called Batch Acquisition Mode (BAM) allowing even more power

consumption saving during data batching.

STM32F412XE/G devices incorporate high-speed embedded memories (up to 1 Mbyte of

Flash memory, 256 Kbytes of SRAM), and an extensive range of enhanced I/Os and

peripherals connected to two APB buses, three AHB buses and a 32-bit multi-AHB bus

matrix.

All devices offer one 12-bit ADC, a low-power RTC, twelve general-purpose 16-bit timers,

two PWM timers for motor control and two general-purpose 32-bit timers.

They also feature standard and advanced communication interfaces:

•

Up to four I2Cs, including one I2C supporting Fast-Mode Plus

•

Five SPIs

•

Five I2Ss of which two are full duplex. To achieve audio class accuracy, the I2S

peripherals can be clocked via a dedicated internal audio PLL, or via an external clock

to allow synchronization.

•

Four USARTs

•

An SDIO/MMC interface

•

A USB 2.0 OTG full-speed interface

•

Two CANs.

In addition, STM32F412xE/G devices embed advanced peripherals:

•

A flexible static memory controller interface (FSMC)

•

A Quad-SPI memory interface

•

A digital filter for sigma modulator (DFSDM), two filters, up to four inputs, and support

of microphone MEMs.

STM32F412xE/G devices are offered in 7 packages ranging from 48 to 144 pins. The set of

available peripherals depends on the selected package.

The STM32F412xE/G operates in the -40 to +125 °C temperature range from a 1.7 (PDR

OFF) to 3.6 V power supply. A comprehensive set of power-saving modes allows the design

of low-power applications.

Features
• Dynamic Efficiency Line with BAM (Batch
Acquisition Mode)
• Core: Arm® 32-bit Cortex®-M4 CPU with FPU,
Adaptive real-time accelerator (ART
Accelerator™) allowing 0-wait state execution
from Flash memory, frequency up to 100 MHz,
memory protection unit,
125 DMIPS/1.25 DMIPS/MHz (Dhrystone 2.1),
and DSP instructions
• Memories
– Up to 1 Mbyte of Flash memory
– 256 Kbyte of SRAM
– Flexible external static memory controller
with up to 16-bit data bus: SRAM, PSRAM,
NOR Flash memory
– Dual mode Quad-SPI interface
• LCD parallel interface, 8080/6800 modes
• Clock, reset and supply management
– 1.7 V to 3.6 V application supply and I/Os
– POR, PDR, PVD and BOR
– 4-to-26 MHz crystal oscillator
– Internal 16 MHz factory-trimmed RC
– 32 kHz oscillator for RTC with calibration
– Internal 32 kHz RC with calibration
• Power consumption
– Run: 112 µA/MHz (peripheral off)
– Stop (Flash in Stop mode, fast wakeup
time): 50 µA Typ @ 25 °C; 75 µA max
@25 °C
– Stop (Flash in Deep power down mode,
slow wakeup time): down to 18 µA @
25 °C; 40 µA max @25 °C
– Standby: 2.4 µA @25 °C / 1.7 V without
RTC; 12 µA @85 °C @1.7 V
– VBAT supply for RTC: 1 µA @25 °C
• 1×12-bit, 2.4 MSPS ADC: up to 16 channels
• 2x digital filters for sigma delta modulator,
4x PDM interfaces, stereo microphone support
• General-purpose DMA: 16-stream DMA
• Up to 17 timers: up to twelve 16-bit timers, two
32-bit timers up to 100 MHz each with up to
four IC/OC/PWM or pulse counter and
quadrature (incremental) encoder input, two
watchdog timers (independent and window),
one SysTick timer
• Debug mode
– Serial wire debug (SWD) & JTAG
– Cortex®-M4 Embedded Trace Macrocell™
• Up to 114 I/O ports with interrupt capability
– Up to 109 fast I/Os up to 100 MHz
– Up to 114 five V-tolerant I/Os
• Up to 17 communication interfaces
– Up to 4x I2C interfaces (SMBus/PMBus)
– Up to 4 USARTs (2 x 12.5 Mbit/s,
2 x 6.25 Mbit/s), ISO 7816 interface, LIN,
IrDA, modem control)
– Up to 5 SPI/I2Ss
