L6206PD013TR motor drive chip ST original stock
describe
The L6206 device is a DMOS dual full bridge designed for motor control applications, implemented using BCD technology, combining isolated DMOS power transistors with CMOS and bipolar circuits on the same chip. The L6206 device can be used in the PowerDIP24 (20+2+2), PowerSO36, and SO24 (20+2+2) software packages, characterized by thermal shutdown and non dissipative overcurrent detection on high side power MOSFETs, as well as diagnostic outputs, making it easy to implement overcurrent protection.
features
The working power supply voltage is 8 to 52 V
5.6 A output peak current (2.8 A DC)
RDS (on) 0.3 Å type. Value at Tj=25 ° C
Operating frequency up to 100 KHz
Programmable high side overcurrent detection and protection
Diagnostic output
Parallel operation
Cross conduction protection
Thermal shutdown
Under voltage locking
Integrated fast freewheeling diode
application
Bipolar stepper motor
The L6206 device is a DMOS dual full bridge designed for motor control applications, implemented using BCD technology, combining isolated DMOS power transistors with CMOS and bipolar circuits on the same chip. The L6206 device can be used in the PowerDIP24 (20+2+2), PowerSO36, and SO24 (20+2+2) software packages, characterized by thermal shutdown and non dissipative overcurrent detection on high side power MOSFETs, as well as diagnostic outputs, making it easy to implement overcurrent protection.
features
The working power supply voltage is 8 to 52 V
5.6 A output peak current (2.8 A DC)
RDS (on) 0.3 Å type. Value at Tj=25 ° C
Operating frequency up to 100 KHz
Programmable high side overcurrent detection and protection
Diagnostic output
Parallel operation
Cross conduction protection
Thermal shutdown
Under voltage locking
Integrated fast freewheeling diode
application
Bipolar stepper motor
Dual or quad DC motors
