ICM-42688-P LGA-14(2.5x3) Attitude Sensor/Gyroscope Yingmeisheng Original Stock
ICM-42688-P FEATURES
• Gyroscope Noise: 2.8 mdps/Hz &
Accelerometer Noise: 70 µg/Hz
o Low-Noise mode 6-axis current
consumption of 0.88 mA
• User selectable Gyro Full-scale range (dps):
± 15.6/31.2/62.5/125/250/500/1000/2000
• User selectable Accelerometer Full-scale
range (g): ± 2/4/8/16
• User-programmable digital filters for gyro,
accel, and temp sensor
• APEX Motion Functions:
o Pedometer, Tilt Detection, Tap Detection
o Wake on Motion, Raise to Wake/Sleep,
Significant Motion Detection
• Host interface: 12.5 MHz I3CSM, 1 MHz I2C,
24 MHz SPI
APPLICATIONS
• AR/VR Controllers
• Head Mounted Displays
• Wearables
• Sports
• Robotics
• IoT Applications
