206061-1 standard ring connector te original stock
206061-1
Specification information:
Manufacturer: te connectivity
Product category: standard ring connector
RoHS: Yes
Product: housings
Number of positions: 4 positions
Contact type: pin (male)
Shell size: 11
Installation style: panel
Termination type:-
Contact plating:-
Shell material:-
Series: CPC
Shell material: thermoplastic
Mounting angle: straight
Installation type: flange with mounting holes
Enclosure type: receptacle
Thread size: 5 / 8-24
Trademark: te connectivity / Amp
Contact material:-
Flammability class: UL 94 V-0
Shell plating:-
Compliance: UL
Not relevant for lead free process
Matching style: Threaded
Product type: standard circular connector
Factory packing quantity: 1
Subcategory: Circular connectors
Length of termination column:-
Trade name: CPC Series 1
Part number alias: 206061-1
Specification information:
Manufacturer: te connectivity
Product category: standard ring connector
RoHS: Yes
Product: housings
Number of positions: 4 positions
Contact type: pin (male)
Shell size: 11
Installation style: panel
Termination type:-
Contact plating:-
Shell material:-
Series: CPC
Shell material: thermoplastic
Mounting angle: straight
Installation type: flange with mounting holes
Enclosure type: receptacle
Thread size: 5 / 8-24
Trademark: te connectivity / Amp
Contact material:-
Flammability class: UL 94 V-0
Shell plating:-
Compliance: UL
Not relevant for lead free process
Matching style: Threaded
Product type: standard circular connector
Factory packing quantity: 1
Subcategory: Circular connectors
Length of termination column:-
Trade name: CPC Series 1
Part number alias: 206061-1
Unit weight: 31.800 G
