292161-3 wire to plate / wire to wire connector te original stock
292161-3
Specification information:
Manufacturer: te connectivity
Product category: header and shell
RoHS: Yes
Product: headers
Type: shrouded
Number of positions: 3 positions
Pitch: 2 mm
Number of rows: 1 row
Installation style:-
Termination type: through hole
Contact type: pin (male)
Contact plating: Tin
Series: amp CT
Trade name: common termination
Contact type: Pin
Current rating: 4 A
Shell material: Nylon
Voltage rating: 125 V
Trademark: te connectivity / Amp
Contact material: Brass
Maximum operating temperature: + 105 C
Minimum operating temperature: - 40 C
Product type: headers & wire housing
Factory packing quantity: 1000
Subcategory: headers & wire housing
Wire gauge: 28 AWG - 22 AWG
Part number alias: 292161-3
Specification information:
Manufacturer: te connectivity
Product category: header and shell
RoHS: Yes
Product: headers
Type: shrouded
Number of positions: 3 positions
Pitch: 2 mm
Number of rows: 1 row
Installation style:-
Termination type: through hole
Contact type: pin (male)
Contact plating: Tin
Series: amp CT
Trade name: common termination
Contact type: Pin
Current rating: 4 A
Shell material: Nylon
Voltage rating: 125 V
Trademark: te connectivity / Amp
Contact material: Brass
Maximum operating temperature: + 105 C
Minimum operating temperature: - 40 C
Product type: headers & wire housing
Factory packing quantity: 1000
Subcategory: headers & wire housing
Wire gauge: 28 AWG - 22 AWG
Part number alias: 292161-3
Unit weight: 154 mg
