770680-1 te automobile connector agent shipment
770680-1
Specification information:
Manufacturer: te connectivity
Product category: Automobile connector
RoHS: Yes
Product: housings
Number of positions: 23 positions
Type: socket (female)
Installation style: wire
Termination type: Crimp
Wire gauge range: 20 AWG to 16 AWG
Series: ampseal
Application: wire to board / device
Contact type: plug
Current rating: 17 A
Height: 1 in
Shell material: other
Entrance protection: ip6k9k
Length: 1.8 in
Material: plastic
Mounting angle: straight
Installation method: no
Number of rows: 3 row
Type: Female
Voltage rating: 250 VAC
Width: 1.5 in
Accessory aperture: 1.3 mm
Trademark: te connectivity
Flammability grade: UL 94V-0
Locking mechanism: integrated in housing
Pitch: 4 mm
Line spacing: 4 inches
Maximum operating temperature: + 125 C
Minimum operating temperature: - 40 C
Product type: automotive connectors
Factory packing quantity: 28
Subcategory: automotive connectors
Wire gauge maximum: 16 AWG
Wire gauge minimum: 20 AWG
Part number alias: 770680-1
Specification information:
Manufacturer: te connectivity
Product category: Automobile connector
RoHS: Yes
Product: housings
Number of positions: 23 positions
Type: socket (female)
Installation style: wire
Termination type: Crimp
Wire gauge range: 20 AWG to 16 AWG
Series: ampseal
Application: wire to board / device
Contact type: plug
Current rating: 17 A
Height: 1 in
Shell material: other
Entrance protection: ip6k9k
Length: 1.8 in
Material: plastic
Mounting angle: straight
Installation method: no
Number of rows: 3 row
Type: Female
Voltage rating: 250 VAC
Width: 1.5 in
Accessory aperture: 1.3 mm
Trademark: te connectivity
Flammability grade: UL 94V-0
Locking mechanism: integrated in housing
Pitch: 4 mm
Line spacing: 4 inches
Maximum operating temperature: + 125 C
Minimum operating temperature: - 40 C
Product type: automotive connectors
Factory packing quantity: 28
Subcategory: automotive connectors
Wire gauge maximum: 16 AWG
Wire gauge minimum: 20 AWG
Part number alias: 770680-1
Unit weight: 25.400 G
