826629-2-pin te connector original stock
826629-2
Specification information:
Manufacturer: te connectivity
Product category: header and shell
RoHS: Yes
Product: headers
Type: breakaway
Number of positions: 2 positions
Pitch: 2.54 mm
Number of rows: 1 row
Installation style:-
Termination type: through hole
Mounting angle: vertical
Contact type: pin (male)
Contact plating: Gold
Length of fitting column: 6.7 mm
Length of terminal post: 3.2 mm
Series: AMPMODU mod II
Trade name: AMPMODU
Encapsulation: bulk
Shell material: thermoplastic (TP)
Trademark: te connectivity
Contact material: phosphor bronze
Flammability class: UL 94 V-0
Line spacing: 2.54 mm
Product type: headers & wire housing
Factory packing quantity: 3000
Subcategory: headers & wire housing
Part number alias: 826629-2
Specification information:
Manufacturer: te connectivity
Product category: header and shell
RoHS: Yes
Product: headers
Type: breakaway
Number of positions: 2 positions
Pitch: 2.54 mm
Number of rows: 1 row
Installation style:-
Termination type: through hole
Mounting angle: vertical
Contact type: pin (male)
Contact plating: Gold
Length of fitting column: 6.7 mm
Length of terminal post: 3.2 mm
Series: AMPMODU mod II
Trade name: AMPMODU
Encapsulation: bulk
Shell material: thermoplastic (TP)
Trademark: te connectivity
Contact material: phosphor bronze
Flammability class: UL 94 V-0
Line spacing: 2.54 mm
Product type: headers & wire housing
Factory packing quantity: 3000
Subcategory: headers & wire housing
Part number alias: 826629-2
Unit weight: 126 mg
