1318747-1 automotive connector te original stock
1318747-1
Specification information:
Manufacturer: te connectivity
Product category: Automobile connector
RoHS: Yes
Product: housings
Number of positions: 32 Positions
Type: socket (female)
Termination type: Crimp
Series: th 025
Application: wire to wire
Color: Natural
Contact type: receptacle
Height: 15.8 mm
Shell material: polybutylene terephthalate (PBT)
Length: 21 mm
Mounting angle: straight
Installation method: no
Number of rows: 2 row
Type: connector
Voltage rating: 12 VDC
Width: 37.4 mm
Trademark: te connectivity / Amp
Locking mechanism: on the terminal
Pitch: 2.2 mm
Line spacing: 5.9 mm
Maximum operating temperature: + 105 C
Minimum operating temperature: - 30 C
Product type: automotive connectors
Factory packing quantity: 100
Subcategory: automotive connectors
Part number alias: 1318747-1
Specification information:
Manufacturer: te connectivity
Product category: Automobile connector
RoHS: Yes
Product: housings
Number of positions: 32 Positions
Type: socket (female)
Termination type: Crimp
Series: th 025
Application: wire to wire
Color: Natural
Contact type: receptacle
Height: 15.8 mm
Shell material: polybutylene terephthalate (PBT)
Length: 21 mm
Mounting angle: straight
Installation method: no
Number of rows: 2 row
Type: connector
Voltage rating: 12 VDC
Width: 37.4 mm
Trademark: te connectivity / Amp
Locking mechanism: on the terminal
Pitch: 2.2 mm
Line spacing: 5.9 mm
Maximum operating temperature: + 105 C
Minimum operating temperature: - 30 C
Product type: automotive connectors
Factory packing quantity: 100
Subcategory: automotive connectors
Part number alias: 1318747-1
Unit weight: 4.624 G
