565790519 MOLEX USB Connector Original Spot

565790519

Specification information:

Unit Pack: 900

Minimum order quantity: 3600

Operating temperature range: -20C to 85C

Number of ports: 1 Port

Contact plating: Gold Over Nickel

Rated current (maximum): 1/Contact A

Type: RCP

Shell material: Polyphthalamide

Installation Style: Through Hole

Style: Right Angle

Encapsulation: Tray

The operating temperature is at maximum Celsius. 85C

Type: USB

Contact material: Copper Alloy

Contact points: 5 POS

Operating temperature sensitivity.:- 20C

Product length (mm): 7.7 mm

Product thickness (mm): 9 mm

Product height (mm): 3.95 mm

Number of terminals: 5

Shape size (mm): 7.7 x 9 x 3.95

Maximum rated voltage: 30V

Termination: Solder

Spacing (mm): 1.6 mm

Connector type:: USB Mini A/B

Contact terminal:Solder

Connector Mounting::PCB

SVHC:: No SVHC (20-Jun-2013)

Contact resistance:: 50 Mohm

Contact to Contact Capacitance::2pF

External depth:: 9.0mm

External Length / Height:: 3.1mm

External width:: 6.9mm

Insulation resistance:: 100 Mohm

Operating Temperature Max::50 C

Operating Temperature Min::0 C

Pressure resistance:: 100VAC

Operating voltage:: 30V

Weight (kg):0.0059

Tariff No.:85369010
