describe

Kintex ®- 7fpgas has 3, 2, 1, 1L and 2L speed levels, -3 has the highest performance- 2L equipment has a lower maximum static power, and can work under a lower core voltage and a lower dynamic power- 2L Industrial (I) temperature device only works at vccint=0.95v- 2L extended (E) temperature device can work at vccint=0.9v or 1.0V. The -2le equipment operating at vccint=1.0v and -2li equipment operating at vccint=0.95v have the same speed specification as the -2 speed class, unless otherwise specified. When the -2le equipment operates at vccint=0.9v, the speed specification, static power and dynamic power are reduced- The 1L military (m) temperature device has the same speed specification as the -1 military temperature device, and shields the lower maximum static power.

The DC and AC characteristics of the kinex-7fpga are suitable for commercial, extended, industrial, extended (-1q) and military (-1m) temperature ranges. Except for the operating temperature range or otherwise specified, all DC and AC electrical parameters for a specific speed class are the same (i.e., the timing characteristics of -1 speed class military temperature devices are the same as those of -1 speed class commercial temperature devices). However, within each temperature range, only the selected speed class and / or equipment is available. For example, -1m is only available in the defense level kintex-7q family, while -1q is only available in the xakintex-7fpga family.

All power supply voltage and junction temperature specifications represent the worst case. The included parameters are common to common designs and typical applications.

Available combinations of devices and packages can be found in the following:

• 7 Series FPGA overview (ds180)

• defense grade 7 Series FPGA overview (DS185)

• Xa kinex-7 FPGA data sheet: overview (ds175)
